HS-K54 Embedded Kiosk Printer 250mm/s High-Speed 80mm Wide Thermal Receipt Printer

Core Product Advantages

1. High-Speed & Wide-Width Printing, Industry-Leading Efficiency：Adopting thermal-line dot printing technology, with a maximum printing speed of 250mm/s and a maximum effective printing width of 80mm, combined with 203DPI clear resolution, it doubles the efficiency when printing tickets and labels in batches, meeting the high-frequency printing needs of self-service terminals.
2. Multiple Intelligent Detection, Stable and Reliable Operation：Integrates multiple sensors such as print head temperature detection, paper out detection, paper near-end detection, paper taken-out detection, black mark/gap detection, and cutter reset detection. It feedbacks device status in real time, prompts faults through indicator light flashing and buzzer alarm, effectively reducing downtime caused by paper jams, paper shortage and other issues.
3. Full-Scenario Paper Adaptation, Flexible and Adjustable：Supports 0.055-0.09mm thermal receipt paper, maximum 0.15mm label paper and black mark paper. The maximum paper roll outer diameter is 150mm, inner diameter is 25mm, and the adjustable paper width of 48-82.5mm supports centered printing, adapting to various specifications of tickets such as scenic spot tickets, cinema tickets, parking coupons and discount coupons.
4. Multi-Interface Compatibility, Easy Integration：Standard equipped with DC+USB+RS232 three-in-one cable, supporting Ethernet (compatible with DHCP) communication. It is compatible with multiple systems such as Windows and Linux, supports ESC/POS command set (including page mode), with strong full-platform adaptability, and can be easily integrated into various self-service terminal equipment.
5. Humanized Design, Easy Operation and Maintenance：Automatic paper feeding function realizes first-ticket positioning and last-ticket printing, making paper loading convenient and efficient; equipped with FEED button (paper feeding/self-test) and TEST button (print NVLOGO/black mark learning), with simple operation logic; metal motor firmware has fast heat dissipation and low power consumption, the cutter life reaches 1 million times, and the print head life is 100km, making it more durable for long-term use.
6. Compact Structure + Flexible Installation：The body size is only 132.1x116.6x72.6mm (excluding paper roll holder), weighing 1.15kg, saving embedded installation space; the optional paper roll holder supports 3-speed angle adjustment and can be installed on the left and right sides, adapting to the internal layout of different self-service terminals.
7. Rich Printing Functions, Meeting Personalized Needs：Supports multiple printing effects such as 1-8x character width and height magnification, bold, reverse white, underline and italic. It is compatible with 1D barcodes such as UPC-A/E and EAN13/8, as well as 2D barcodes such as QR Code and PDF417. It can customize NVLOGO, adapting to diverse ticket printing scenarios.

Applicable Scenarios

Widely used in self-service terminal equipment (self-service ticket machines, self-service payment machines, self-service queuing machines, self-service vending machines), cultural tourism and entertainment (scenic spot ticket printing, cinema movie ticket printing, amusement park ticket output), transportation (parking payment vouchers, highway toll receipts, online car-hailing vouchers), government affairs (government service receipts, certificate processing vouchers, social security and provident fund documents), commercial retail (mall discount coupons, membership vouchers, self-service cash register receipts), catering services (self-service ordering receipts, takeaway order tickets) and other scenarios. It is especially suitable for self-service equipment integration that requires high-frequency and high-stability embedded printing.

Standard Accessories

Printer host, DC+USB+RS232 three-in-one cable, Ethernet interface cable, mounting screws, user manual, paper roll pressure roller, optional paper roll holder, power adapter (110V-220V input, DC24V 2A output)
